接头
代号(订货号)
|
管子外径
|
D
|
D1
|
D0
|
H
|
H1
|
重量(kg)
|
ZT6.5.13-1
|
42
|
32
|
42.5
|
60
|
36
|
18
|
0.73
|
ZT6.5.13-2
|
48
|
38
|
48.5
|
70
|
41
|
20
|
0.92
|
ZT6.5.13-3
|
60
|
49
|
60.5
|
80
|
48
|
23
|
1.43
|
标记示例:接头42 ZT6.5.13-1电动润滑泵
变径接头
代号(订货号)
|
管子外径(D0)
|
D
|
D1
|
D2
|
D3
|
L
|
L1
|
重量(kg)
|
ZT6.5.31-1
|
34×42
|
34.5
|
55
|
25
|
41
|
48
|
17
|
0.48
|
ZT6.5.31-2
|
42×48
|
42.5
|
60
|
32
|
48
|
52
|
18
|
0.54
|
ZT6.5.31-3
|
48×60
|
48.5
|
70
|
38
|
60
|
56
|
20
|
0.87
|
三通
代号(订货号)
|
管子外径(D0)
|
D+0.4
+0.2 |
D1
|
D2
|
L
|
L1
|
L2
|
B
|
R
|
重量(kg)
|
对应号
|
ZT6.5.36-1
|
18
|
18.5
|
12
|
27
|
27
|
17
|
12
|
24
|
12
|
0.18
|
H1.12-1
|
T6.5.36-2
|
22
|
22.5
|
16
|
33
|
29
|
19
|
13
|
28
|
14
|
0.27
|
H1.12-2
|
ZT6.5.36-3
|
28
|
28.5
|
20
|
41
|
35
|
20
|
14
|
36
|
18
|
0.45
|
H1.12-3
|
ZT6.5.36-4
|
34
|
34.5
|
25
|
47
|
39
|
22
|
16
|
44
|
22
|
0.59
|
H1.12-4
|
ZT6.5.36-5
|
42
|
42.5
|
32
|
57
|
45
|
24
|
18
|
52
|
26
|
0.62
|
H1.12-5
|
ZT6.5.36-6
|
48
|
48.5
|
36
|
64
|
52
|
28
|
20
|
60
|
30
|
1.35
|
H1.12-6
|
ZT6.5.36-7
|
60
|
61
|
48
|
76
|
61
|
30
|
23
|
72
|
36
|
2.20
|
H1.12-7
|
标记示例:三通18 ZT6.5.36-1
